WIDELY USEDIdeal for use when pumping from external Water Oil Fuel containers, Submersible Fuel Pump.
TRANSFER PUMPThe red click is to connect positive pole, the black click is to connect negative pole. You need to connect correctly the positive and negative pole.
SPECIFICATIONSVoltage: DC 12v. Power: 12v 1.5A. Pressure head: 2.5M. Absorption process: 1.5M. Cable Length: about 3M. Motor speed: 8700r / min.
SUPER DURABLEStainless steel shell not easy to deformation, but also to prevent the shell rust, rot. With a stainless steel filter, make the extracted (or water) cleaner.
Sincere Service”COROTC” Professional Fuel Transfer Pump Manufacturer. If you are not completely satisfied with your order, Please contact us, We will give you a satisfactory solution.
12V Fuel Transfer Pump, Mini Portable Stainless Steel On/Off Switch Oil Fuel Transfer Water Pump 12V 40mm
Specifications:

Material: stainless steel+Aluminum Alloy
Color: silver
Size: about 140x38mm
Pump diameter: about 38mm
Voltage: DC 12V
Current: 1.8A
Maximum load current of 1.5A
Motor speed: 8700r / min
Traffic: 12 L / min
Flow rate up to 30l/min
Pressure head: 2.5M, Absorption process: 1.5M. Cable Length: about 3M.
Dimension: Outer diameter: 50mm, Tubing Diameter: 19mm
Do not use the pump more than 20 minutes continuously. WARNING: PETROL OR ANY FLAMMABLE LIQUIDS ARE STRICTLY PROHIBITED TO USE WITH THIS PUMP.
How to use (Instructions)

1. the pump pumping should first take a good self-contain oil hose, and then the pump completely into the clean oil (or water)
2.The pump after use, should put the oil from the oil (or water out)
3.The bottom of the oil pump filter with stainless steel filter, so that the pumping out more clean disel (or water) .Bottom filter with a threaded interface, convenient disassembly, repair, replacement, to achieve the purpose of repeated use
4.The pump maximum output of oil of 12 L / min
5.Note: This pump is pumping gasoilne and other flammable liquids
Warning:

1.The pump is prohibited pumping gasoline,alcohol and other flammable liquids. Can not load and run dry pumping.
2.The pump should be intermittent work(ie each time to use no more than 20 minutes, stop for 10minutes and then continue to use)pay attention to work for not long time
3.Before use should confirm whrther the power and pump laeling voltage line, voltage tolerance 5%, note the postive and negative pole.
Package included:

1 x 38mm Car Oil Liquid Electric Fuel Transfer Pump
