12V Starter for Kawasaki UTV KAF300 Mule 286CC 500 520 550 (For: More than one vehicle)

12V Starter for Kawasaki UTV KAF300 Mule 286CC 500 520 550 (For: More than one vehicle)

SKU QDMD.11982 128000-9980 Category Tag
SPREAD THE LOVE

Description

This is a Brand New Starter for Cub Cadet and Kawasaki

Models:

Cub Cadet Outdoor Power Equipment

Utility Vehicle (UTV)

2003 Big Country 4×2 Kawasaki 9.5HP Engine
2004 Big Country 4×2 Kawasaki 9.5HP Engine
2005 Big Country 4×2 Kawasaki 9.5HP Engine

Kawasaki Powersport

Utility Vehicle (UTV)

KAF300 Mule 500 A1 286cc

KAF300 Mule 500 B1-B2 286cc

KAF300 Mule 520 D1-D2 286cc

KAF300 Mule 550 C1-C7 286cc

Replaces:

Kawasaki
21163-2109

Nippondenso
128000-9980

Remy Small Motor
RS41293

OEM: Denso
Type: DD
Voltage: 12 Volts
kW: 0.6 kW
Rotation: CW
Teeth/Splines: 9 Teeth/Splines
Pinion/Splines OD: 29.5 mm / 1.161 in
Mounting Hole 1: 10.0 mm ID Unthreaded
Mounting Hole 2: 10.0 mm ID Unthreaded
Approximate Weight: 7.1 lbs / 3.23 kg
