Fluid Cooler:
Universal 25 stacked plate aluminum heavy duty engine transmission cooler.
Minimal pressure drop and to be used for engine, transmission or fuel cooling.
Furnace brazed aluminum construction with 4 integrated mounting brackets.
Full 2″ deep turbulator-equipped plates and a matte black powder coat finish.
Dimensions: 2″ x 8.2″ x 13″ with 6AN end fittings and 46000 BTU per hour.
Electric Fan:
Universal 12 volt high performance 6″ inch small electric cooling fan.
Upgraded 90 watt motor draws 7.5 amps, producing over 513 CFM.
Configured as an air puller to be on the inside and pull air through.
Includes mounting bracket feet and complete install fin tie strap kit.
Measures 7.2″ x 7″ x 2.4″ thickness at center and slim 1.4″ at edge.
