400mm 15.34″ Motorcycle Air Shock Absorber Rear Suspension Motor Fit for Dirt Bike Motor Fit for Scooter ATV Quad D30 Motorcycle Suspension Strut Motorcycle Shock Absorber
SPREAD THE LOVE
Description
Made of high material for durability and stability
Pressure can be adjusted by springs or air (nitrogen); Operation of the coil-over springs and air cylinder is helpful to reduce the shock
No instruction included, professional installation recommended
The suspension leg provides a smoother ride and better shock absorption management. The spring seat is insulated from the spring to ensure a quiet and comfortable ride
The suspension shocks struts provides a smoother ride and better overall damping management
Detail
Material: 6063 Aluminum
Total Length: 430mm (17″)
Eye To Eye Center Length: 400mm (15 3/4″)
Eye Diameter: 12 mm (0.47 inch)
Eye thickness : 21 mm (0.83 inch)
Spring thickness: 8 mm (0.31 inch)
Spring Width(approx): 60 mm (2.36inch
Max loading:
<;=300kg/pair
<;=660lb/pair
Package included:
2*Shock Absorber
2*12mm copper rings
2*Adjuster
Note:
This product is measured by hand and may have an error of 1-3cm, which is based on the actual product.
If you have any questions, please feel free to email!
This type of motorcycle shock absorber is designed to reduce the vibration caused by rough roads.
