5020826 1543326 7542439 7515472 Rear Control Arm Bushing Kit For Polaris
SPREAD THE LOVE
Description
Premium Quality Replacement Part
Rear Upper Left or Right Control Arm Bushing Kit
Compatible with Polaris Models:
Sportsman 450 HO 2×4 2016-2017
Sportsman 570 EPS 2016-2017
Sportsman 570 Touring 2016-2017
Sportsman 570 6×6 Big Boss 2017-2023
Sportsman X2 570 EPS 2017
Sportsman SP 570 EPS 2016
Order Includes:
2 x Long Pivot Shaft: 5020826
Length : 74 mm – 2 91 in
Inner Diameter : 10 mm – 0.39 in
Outer Diameter : 16 mm – 0.62 in
Material: Steel
4 x Bushing: 1543326
Length: 29 7mm – 1 17 in
Inner Diameter: 16mm – 0 6 in
Head Diameter: 31 5mm – 1 24 in
Tube Diameter: 21mm – 0 82 in
Material: Plastic
2 x Nut: 7542439, 7542453
Width: 11.2mm – 0 44 in
Inner Diameter: 8 mm – 0 31 in
Outer Diameter: 14.2 mm – 0 55 in
Thread Size: 3/8-24
Material: Iron
2 x Bolt: 7515472
Length: 100.5 mm – 3.95 in
Stud Length: 28mm – 1.1 in
Head Diameter: 14 mm – 0.55 in
Thread Size: M10-1.0
Note: Installs On Location (A) & (B) In Second Picture
Rear Upper Control Arm Part Number:
Left: 1017747-458, 1017747-067
Right: 1017748-458 1017748-067
Rear Lower Control Arm Part Number:
Left: 1015888-458, 1015888-067
Right: 1015889-458, 1015889-067
Knuckle Part Number:
Left & Right: 5135563
