Fluid Cooler:
Universal 6 row tube and fin aluminum light duty transmission cooler kit.
Extend transmission life by preventing heat-related transmission failures.
Perfect for high-stressed smaller and mid-size truck auto transmissions.
High efficiency turbulation and ultrasonically soldered for the best reliability.
Dimensions: 0.75″ x 7.5″ x 15.875″ with 3/8″ barb inlets, GVW 15500 lbs.
Electric Fan:
Universal 12 volt high performance 6″ inch small electric cooling fan.
Upgraded 90 watt motor draws 7.5 amps, producing over 513 CFM.
Configured as an air puller to be on the inside and pull air through.
Includes mounting bracket feet and complete install fin tie strap kit.
Measures 7.2″ x 7″ x 2.4″ thickness at center and slim 1.4″ at edge.
Wiring Kit:
Universal electric fan or automotive accessory wire harness kit.
Safely powers one 12 volt fan or auto accessory without splicing.
Maximum 20 amp continuous draw with in-line fuse protection.
Standard 7 feet of 14AWG size wiring allows mounting flexibility.
Installation instructions and all pictured components included.
