Fluid Cooler:
Universal 6 row tube and fin aluminum light duty transmission cooler kit.
Extend transmission life by preventing heat-related transmission failures.
Perfect for high-stressed smaller and mid-size truck auto transmissions.
High efficiency turbulation and ultrasonically soldered for the best reliability.
Dimensions: 0.75″ x 7.5″ x 15.875″ with 3/8″ barb inlets, GVW 15500 lbs.
Electric Fan:
Universal 12 volt high performance 6″ inch small electric cooling fan.
Upgraded 90 watt motor draws 7.5 amps, producing over 513 CFM.
Configured as an air puller to be on the inside and pull air through.
Includes mounting bracket feet and complete install fin tie strap kit.
Measures 7.2″ x 7″ x 2.4″ thickness at center and slim 1.4″ at edge.
Wiring Kit:
Universal automotive electric fan 5-pin 40A relay switch harness kit.
14AWG size wire powers 1-2 cooling fans or 12 volt auto accessories.
Maximum 30 amp continuous draw with 30A in-line fuse protection.
A/C override or manual toggle switch wire built directly into harness.
Installation instructions, wiring diagram and components included.
Thermostat:
Universal adjustable automotive electric fan thermostat switch sensor.
Turn-on range of 32-248’F with turn-off always set at 15 degrees less.
3 pin design allows for wiring as a normally open or closed circuit.
Probe pushes between radiator fins or inserts into coolant hose line.
Detailed install instructions, wiring diagram and hardware included.
