Premium Quality Replacement Part
Clutch Rebuild Kit w/ Spring for Polaris RZR XP 1000 Trail & Rocks 2017-2021
**Note**
This Kit Includes the 29-75 Weight
Kit Includes:
1x Spring
6x Clutch Buttons
3x Clutch Bushings
3x Roller Pins
6x Clutch Spider Washer
1x Set of Clutch Weights 29-75
3x Shoulder Bolts
3x Lock Nuts
Fits the Following Polaris Models
RZR XP 1000 2017-2021
RZR XP 1000 MD 2017-2019
RZR XP 4 1000 2017-2021
RZR XP 4 1000 MD 2017-2019
RZR XP 1000 TRAILS & ROCKS 2017-2021
RZR XP 1000 High Lifter Edition 2017-2021
RZR XP 1000 Ride Command Edition 2017-2021
RZR XP 1000 TRACTOR/EU/ZUG 2017-2021
Replaces POLARIS Part Numbers
Clutch Weight 29-75 | 5633720
Roller Pin | 5020422
Clutch Washer | 5438247
Clutch Button 16.7mm | 5450940
Roller Bushing | 1321622
Shoulder Bolt | 7512266
Lock Nut | 7541906
Spring | 7044465
Dimensions & Measurements
Belt
1086mmx31mmx17mm
Clutch Bushings
14.25mm Outer Diameter
9.6mm Inner Diameter
13.85mm Width
Clutch Pins
9.6mm Diameter
25mm Length
Buttons
16.7mm Diameter
6.7mm Height
Spider Washer
14.4mm Outer Diameter
9.6mm Inner Diameter
1.5mm Thick
**
