Front A Arm Bushing Kit For Polaris Sportsman 450 2016-2019 ACE 570 2016-2019
Front A Arm Bushing Kit For Polaris Sportsman 450 2016-2019 ACE 570 2016-2019 - Image 2
Front A Arm Bushing Kit For Polaris Sportsman 450 2016-2019 ACE 570 2016-2019 - Image 3
Front A Arm Bushing Kit For Polaris Sportsman 450 2016-2019 ACE 570 2016-2019 - Image 4
Front A Arm Bushing Kit For Polaris Sportsman 450 2016-2019 ACE 570 2016-2019 - Image 5

Front A Arm Bushing Kit For Polaris Sportsman 450 2016-2019 ACE 570 2016-2019

SKU ChT.04548 5139929 7556153 1543326, 1542161-458 1542161-067 1542162-458 1542162-067 Category Tags , , , ,
SPREAD THE LOVE

Description

Premium Quality Replacement Part
Front Lower Left & Right Inner A Arm Bushing Kit
For Polaris Models:
Sportsman 450 HO 2×4 2016-2019
Sportsman 570 EPS 2016-2020
Sportsman 570 Touring 2016-2017
Sportsman SP 570 EPS 2016
Sportsman 570 6×6 Big Boss 2017
Sportsman X2 570 EPS 2017
ACE 570 EPS 2016-2019
Order Includes:
2 x Long Pivot Shaft: 5139929
Length: 282.6mm
Inner Diameter: 8.2mm
Outer Diameter: 16mm
4 x Flange Washer: 7556153
Thickness: 2mm
Inner Diameter: 10 6mm
Outer Diameter: 19 8mm
4 x Bushing: 1543326
Length: 29 7mm
Inner Diameter: 16 mm
Head Diameter: 31 5mm
Tube Diameter: 21mm
Front Lower A Arm Part Number
Left: 1542161-458 1542161-067
Right: 1542162-458 1542162-067
