Front And Rear CV Axles For Kawasaki Teryx 800 KRF800 LE 2014-2021
SPREAD THE LOVE
Description
Premium Quality Replacement Part
Front And Rear CV AxleFor Kawasaki Models:Teryx 800 KRF800 LE 2014-2021Order Includes:
2x Rear CV Axle : 59266-0046, 59266-0703
Length : 752.5 mm | 29.62 ”
Spline A Length : 45mm | 1.77 ”
Spline A Boot Width : 77 mm | 3.03 ”
SPline A – 20 Tooth
Spline B Length : 29 mm | 1.14 ”
Spline B Boot Width : 73.2 mm | 2.88 ”
Spline B – 20 Tooth
1x Front Left CV Axle : 59266-0047, 59266-0707
Length : 730.2 mm | 28.7 ”
Spline A Length : 37.6 mm | 1.4 ”
Spline A Boot Width : 88.5 mm | 3.4 ”
Spline A – 26 Tooth
Spline B Length : 70.6 mm | 2.7 ”
Spline B Boot Width : 80.5 mm | 3.1 ”
Spline B – 26 Tooth1x Front Right CV Axle : 59266-0047, 59266-0707
Length : 698.5 mm | 27.5 ”
Spline A Length : 36.14 mm | 1.42 ”
Spline A Boot Width : 89.5 mm | 3.52 ”
Spline A – 26 Tooth
Spline B Length : 27.9 mm | 1.09 ”
Spline B Boot Width : 80.4 mm | 3.16 ”
Spline B – 26 Tooth
**
