Front and Rear Engine Mount Rubber Dampers For Yamaha Grizzly YFM660 2002-2008
SPREAD THE LOVE
Description
Front and Rear Engine Mount Rubber Dampers For Yamaha Grizzly YFM660 2002-2008
Complete Set of Rubber Damper Engine Mounts for Yamaha Grizzly
Check below to verify fitment and measurments!
Fits the Following YAMAHA Models
Grizzly 660 YFM660F 2002-2008 ALL MODELS
Replaces YAMAHA Part Numbers
Engine Mount Rubber Damper 2 | 5KM-21486-10-00 | 5KM-21486-00-00
Engine Mount Rubber Damper 1 | 5KM-21485-10-00 | 5KM-21485-00-00
Dimensions & Measurements
BOTH
LENGTH | 61mm
WIDTH | 54mm
HEIGHT | 20mm
MOUNT BOLT | M10 X 1.25
DAMPER 2
SMALL MOUNT HOLE DIAMETER | 7mm
SMALL MOUNT HOLE OFFSET | 15mm
LARGE MOUNT HOLE DIAMETER | 10.5mm
LARGE MOUNT HOLE OFFSET | 21MM
DAMPER 1
SMALL MOUNT HOLE DIAMETER | 7mm
SMALL MOUNT HOLE OFFSET | 12mm
LARGE MOUNT HOLE DIAMETER | 9mm
LARGE MOUNT HOLE OFFSET | 15MM
Order Includes
2x FRONT RUBBER DAMPER ENGINE MOUNT
2x REAR RUBBER DAMPER ENGINE MOUNT
**
