Front Brake Disc & Caliper Kit for CanAm Outlander 1000R XMR 2018-2022

Front Brake Disc & Caliper Kit for CanAm Outlander 1000R XMR 2018-2022
High Quality Brake Disk Rotor and Caliper Kit for Can-Am Outlander
This is a complete kit for the FRONT brakes
Left and Right disks are interchangeable
Kit comes with specific Left and Right Calipers
Fits the Following Can-Am Models
Outlander 450 2018-2022
Outlander 570 2018-2022
Outlander 570 XMR 2020-2021
Outlander 650 2020-2022
Outlander 650 XMR 2020-2022
Outlander 850 2018-2022
Outlander 850 XMR 2020-202
Outlander 1000R 2018-2022
Outlander 1000R XMR 2018-2022
Outlander MAX 2016
Outlander MAX 450 2017-2022
Outlander MAX 570 2017-2022
Outlander MAX 650 2017-2022
Outlander MAX 850 2017-2022
Outlander MAX 1000 2017
Outlander MAX 1000R 2018-2022
Outlander 1000 6×6 2016-2018
Outlander MAX 1000 6×6 2019-2022
Outlander MAX 650 6×6 2019-2022
Outlander MAX 450 6×6 2019-2022
Replaces Can-Am Part Numbers
Brake Disc | 705600999
Left Front Caliper | 705600862
Left Front Caliper | 705600861
Dimensions & Measurements
DISC
Diameter | 215mm
Bolt Spacing | 136mm
Thickness | 4.6mm
Bolt Hole Size | M8
CALIPER Left/Right
Bolt Spacing | 89mm
Length x Width | 134mm x9 5mm
Order Includes
2x Front Brake Disc
1x Front Left Brake Caliper w/ Pads
1x Front Right Brake Caliper w/ Pads
**
