Front or Rear Knuckle Shaft Collar For Yamaha Rhino 660 05-07 / 90387-30008-00
Front or Rear Knuckle Shaft Collar For Yamaha Rhino 660 05-07 / 90387-30008-00 - Image 2
Front or Rear Knuckle Shaft Collar For Yamaha Rhino 660 05-07 / 90387-30008-00 - Image 3
Front or Rear Knuckle Shaft Collar For Yamaha Rhino 660 05-07 / 90387-30008-00 - Image 4
Front or Rear Knuckle Shaft Collar For Yamaha Rhino 660 05-07 / 90387-30008-00 - Image 5

Front or Rear Knuckle Shaft Collar For Yamaha Rhino 660 05-07 / 90387-30008-00

SKU ZH.00132 90387-30008-00, 903873000800 Category Tags ,
SPREAD THE LOVE

Description

Premium Quality Replacement Part
Front or Rear Left Right Knuckle Shaft Collar
Compatible with Yamaha Models:
Front Wheel
Kodiak 400 4×4 2006
Kodiak 450 4×4 2005-2006
Rhino 450 4×4 2006-2009
Rhino 660 4×4 2005-2007
Rhino 700 4×4 2008-2009 2011-2013
Grizzly 400 4×4 2007-2008
Grizzly 450 4×4 2007-2012
YXZ1000 2016
YXZ1000R 2017-2018
Rear Wheel
Rhino 660 4×4 2005-2007
Rhino 450 4×4 2006-2009
Rhino 450 4×4 2006-2009
Order Includes:
4 x Collar: 90387-30008-00
Width: 10.5 mm – 0.41 in
Inner Diameter: 30.2 mm – 1 18 in
Outer Diameter: 39.1 mm – 1 53 in
Front Knuckle Part Number:
Left:1D9-F3501-03-00, 1D9-F3501-00-00, 1D9-F3501-01-00
1D9-F3501-02-00, 2HC-F3501-00-00, 2HC-F3501-10-00, 5UG-F3501-12-00
5UG-F3501-00-00, 5UG-F3501-10-00, 5UG-F3501-11-00
Right: 1D9-F3502-03-00, 1D9-F3502-00-00, 1D9-F3502-01-00
1D9-F3502-02-00 , 2HC-F3502-00-00, 2HC-F3502-10-00, 5UG-F3502-12-00
5UG-F3502-00-00, 5UG-F3502-10-00, 5UG-F3502-11-00
Rear Knuckle Part Number:
Left: 5UG-F530F-10-00 5UG-F530F-11-00, 5B4-F530F-00-00
Right: 5UG-F530F-11-00, 5UG-F530F-10-00, 5UG-F530F-00-00, 5B4-F532F-00-00
