Lawn Mower Spindle Assembly for John Deer GY20050 GY20785 L100 L107 L108 L110 L120 L130 GX20250 with 1067mm 42 inch and 1912mm 48 inch Deck with 4 Tapped Bolts

Categories
Product tags
air filter axle bearing belt bracket brake brake cable brake disc carburetor car lamp car light centrifugal clutch clutch clutch cable clutch parts clutch pulley disk brake drive belt electromagnetic valve front fork gasket holder ignition coil ignition spark booster jump-spark coil Lamps Lift Kit Lights lowering kit protective cover pulley clutch shaft shock absorber solenoid solenoid valve spark coil sparking coil starter motor switch throttle cable tire tool tyre washer wheel hub
Lawn Mower Spindle Assembly for John Deer GY20050 GY20785 L100 L107 L108 L110 L120 L130 GX20250 with 1067mm 42 inch and 1912mm 48 inch Deck with 4 Tapped Bolts
Lawn Mower Spindle Assembly for John Deer GY20050 GY20785 L100 L107 L108 L110 L120 L130 GX20250 with 1067mm 42 inch and 1912mm 48 inch Deck with 4 Tapped Bolts - Image 2
Lawn Mower Spindle Assembly for John Deer GY20050 GY20785 L100 L107 L108 L110 L120 L130 GX20250 with 1067mm 42 inch and 1912mm 48 inch Deck with 4 Tapped Bolts - Image 3
Lawn Mower Spindle Assembly for John Deer GY20050 GY20785 L100 L107 L108 L110 L120 L130 GX20250 with 1067mm 42 inch and 1912mm 48 inch Deck with 4 Tapped Bolts - Image 4
Lawn Mower Spindle Assembly for John Deer GY20050 GY20785 L100 L107 L108 L110 L120 L130 GX20250 with 1067mm 42 inch and 1912mm 48 inch Deck with 4 Tapped Bolts - Image 5

Lawn Mower Spindle Assembly for John Deer GY20050 GY20785 L100 L107 L108 L110 L120 L130 GX20250 with 1067mm 42 inch and 1912mm 48 inch Deck with 4 Tapped Bolts

SKU LJG.03314 Category Tags , ,
SPREAD THE LOVE

Description

For John Deere:GY20050 GY20785, with 4pcs tapped mounting screws and pre-lubricated zerk grease.
For L100, L107, L108, L110, L120, L130, and GX20250 with 1067 mm (42″) and 1219 mm (48″) decks.
For Bynorm 090-169,Dealer Choice 39-2210,NHC 251-5593,82-356,Prime Line 7-03175,11206,285-093,Sunbelt B1JD37,Raisman 80-12-073,C-SPN-0006.
Includes: housing,shaft,2 bearing,grease fitting,spacer,nut,blade adapter,Top lock nut,tapped screw.
Height: 6-6/16″ (162mm);Spacing of the holes for the mounting bolts:4-3/16″ (107mm).Good quality with strong package.
Suitable Models
L100,L107,L108, L110,L120, L130, GY20050, GY20785 and GX20250 with 1067mm (42″) and 1219mm (48″) decks.
Oregon: 82-356; Rotary: 11206.
Stens: 285-093; Sunbelt: B1JD37.
Raisman: 80-12-073; C-SPN-0006.
Bynorm: 090-169; NHC: 251-5593.
Prime Line: 7-03175.
Dealer Choice: 39-2210.
And other suitable models.
