Compatible with Snow blower ATV Utility Vehicle Snowmobile Golf Cartawn and Garden
Replace for 334019 MTD725-04437 35510 raftman / Poulan 109081X 109946 146154 Bolens 175213 1753539 Brigg & Stratton 5410K Case C-266525 C33025
Replace for 1-513075 Gilson 212655 184251 Gravley 45071 Lawn Boy 740207 Simplicity17005 16771993 16852960 Snapper 701860 Toro47-1910 110116 1101162 110167
Universal Starter relay12 Volts 4 Terminals Intermittent Duty. Dual post position allows for usage in a variety of year models.
Spec
Voltage12V
Terminals4 Terminals
DutyIntermittent Duty
Mounting TypeUniversal Bracket
Contact MaterialCooper
Resistance 2.9 Ohm
Work Current 50A
Inrush Current60A
Application
Replace for 35510
Replace for Craftman Poulan 109081X 109946 146154
Replace for725-04437
Replace for Bolens 175213 1753539
Replace for Brigg Stratton 5410K
Replace for Case C-266525 C33025
Replace for 1-513075
Replace for Gilson 212655
Replace for 184251
Replace for Gravley 45071
Replace for Lawn Boy 740207
Replace for 17005 16771993 16852960
Replace for Snapper 701860
Replace for 47-1910 110116 1101162 110167
Note
Take care not to overtighten the nut/terminal during installation.
