Winch Solenoid Relay Fit for Warn 12 Volt Heavy Duty 28396 15-487 440262 546-033 1231A WS487
Winch Solenoid Relay Fit for Warn 12 Volt Heavy Duty 28396 15-487 440262 546-033 1231A WS487 - Image 2
Winch Solenoid Relay Fit for Warn 12 Volt Heavy Duty 28396 15-487 440262 546-033 1231A WS487 - Image 3
Winch Solenoid Relay Fit for Warn 12 Volt Heavy Duty 28396 15-487 440262 546-033 1231A WS487 - Image 4
Winch Solenoid Relay Fit for Warn 12 Volt Heavy Duty 28396 15-487 440262 546-033 1231A WS487 - Image 5

Winch Solenoid Relay Fit for Warn 12 Volt Heavy Duty 28396 15-487 440262 546-033 1231A WS487

SKU DCF.01701 Category Tags , ,
SPREAD THE LOVE

Description

REPLACE For Heavy Duty 28396 72631 15-487 67-710 440262 546-033 1231A WS487 ARROWHEAD SMR6005 SMR6005K2 J&N 240-20022
FIT ForWARN Winch Models including M6000 M8000 M8000S XD9000 XD9000i 9.5ti VR 8000 10000 12000 16.5ti 16.5ti-S
SPEC12V 4 terminal Intermittent Duty
NOTETake care not to overtighten the nut/terminal during installation.
1 YEAR WARRANTYPlease feel free to contact us for any questions, we give quick response.
Spec
Voltage: 12 V
Terminals: 4
Intermittent Duty
Resistance3.4
Isolated Base
Work Current50A
Inrush Current60A
High Current Stud of Around 5/16 Inch
Low Current Stud of 0.19 Inch
Mounting Type Flat 180
Contact Material Cooper
Body Shell PlatingZinc Coating
Package Weight0.66lb
Package Size3*3*2.5 Inch
Note
You’d better often check the nuts because they may become loose over time.
