4 Pole Starter Solenoid Replaces 5410K,Cub Cadet, Craftsman, 109946 MTD,Mower AM133094 AM138497, L100 L110 L118 L120 L130

Categories
Product tags
air filter axle bearing belt bracket brake brake cable brake disc carburetor car lamp car light centrifugal clutch clutch clutch cable clutch parts clutch pulley disk brake drive belt electromagnetic valve front fork gasket holder ignition coil ignition spark booster jump-spark coil Lamps Lift Kit Lights lowering kit protective cover pulley clutch shaft shock absorber solenoid solenoid valve spark coil sparking coil starter motor switch throttle cable tire tool tyre washer wheel hub
4 Pole Starter Solenoid Replaces 5410K,Cub Cadet, Craftsman, 109946 MTD,Mower AM133094 AM138497, L100 L110 L118 L120 L130
4 Pole Starter Solenoid Replaces 5410K,Cub Cadet, Craftsman, 109946 MTD,Mower AM133094 AM138497, L100 L110 L118 L120 L130 - Image 2
4 Pole Starter Solenoid Replaces 5410K,Cub Cadet, Craftsman, 109946 MTD,Mower AM133094 AM138497, L100 L110 L118 L120 L130 - Image 3
4 Pole Starter Solenoid Replaces 5410K,Cub Cadet, Craftsman, 109946 MTD,Mower AM133094 AM138497, L100 L110 L118 L120 L130 - Image 4
4 Pole Starter Solenoid Replaces 5410K,Cub Cadet, Craftsman, 109946 MTD,Mower AM133094 AM138497, L100 L110 L118 L120 L130 - Image 5

4 Pole Starter Solenoid Replaces 5410K,Cub Cadet, Craftsman, 109946 MTD,Mower AM133094 AM138497, L100 L110 L118 L120 L130

SKU DCF.01714 146154 Category Tags , ,
SPREAD THE LOVE

Description

12 Volt with 4 Post/ Dual Mounting Bracket with the External Ground including Spade Converters
Replace:Poulan 146154, 109081X, 109946, 192507;35510, 5410K
Replaces Bolens 1752137, 1753539, Case C-266525, C33025; 1-513075, Gilson 212655, 184251, Gravely 45071
Coil Roll is using 180 copper wire, Robust plastic Shell is More durable and upgrade heat resistance performance
100% high quality & Oem Match, direct replacement,6 Month Warranty/ Free Return and Exchang, Full Refund
When Ignition Key is On, The 12Volt Current Flow Go Accross Through the Two Big Terminal and Then the Plunger Move Up.
relay
Continous Duty Solenoid
Heavy Duty Solenoid
12v solenoid relay
waterproof solenoid relay
Heavy Duty
180 copper coil wire rolls upgrade the conductivity of the product
Water-Resistant
Powered Outer and Potted Coil Interiors protect YOUR solenoid against any harsh environment
Dustproof
Firmly Enclosed for overall protection from dust, dirt, sand and any other substance that could cause damage to YOUR Solenoid.
Selling Service
100% OEM Match and Replacement
