REPLACE FORClub Car 8016
APPLICATIONCompatible with 1976-1998 36V electric Club Car DS Golf Carts
SPEC36 Volt 4terminal Continuous Duty
NOTETake care not to overtighten the nut/terminal during installation.
1 YEAR WARRANTYPlease feel free to contact us for any questions, we give quick response.
Spec
Voltage: 36V
Terminals:4
Duty Continuous
OEM8016
High Current Stud: 5/16 Inch
Low Current Stud0.19 Inch
Mounting Type: Flat 180
Contacts Material: Cooper
Housing Material: PMC
Body Shell Plating:Zinc Coating
Potted coil: Cooper
Resistance: 58
Work Current: 50A
Inrush Current: 60A
Package Weight: 0.88lb
Package Size:3.5*3*3 Inch
Note
You’d better often check the nuts because they may become loose over time.
