Heavy Duty Solenoid Relay 12 Volt Compatible With White Rodgers 120-105851 120-105851-6 120-913S1 AM105171 AM103290 AM30182 AM52191 AM53945 281777826277
Heavy Duty Solenoid Relay 12 Volt Compatible With White Rodgers 120-105851 120-105851-6 120-913S1 AM105171 AM103290 AM30182 AM52191 AM53945 281777826277 - Image 2
Heavy Duty Solenoid Relay 12 Volt Compatible With White Rodgers 120-105851 120-105851-6 120-913S1 AM105171 AM103290 AM30182 AM52191 AM53945 281777826277 - Image 3
Heavy Duty Solenoid Relay 12 Volt Compatible With White Rodgers 120-105851 120-105851-6 120-913S1 AM105171 AM103290 AM30182 AM52191 AM53945 281777826277 - Image 4
Heavy Duty Solenoid Relay 12 Volt Compatible With White Rodgers 120-105851 120-105851-6 120-913S1 AM105171 AM103290 AM30182 AM52191 AM53945 281777826277 - Image 5

Heavy Duty Solenoid Relay 12 Volt Compatible With White Rodgers 120-105851 120-105851-6 120-913S1 AM105171 AM103290 AM30182 AM52191 AM53945 281777826277

SKU DCF.01859 20-105851 120-105851-6 120- 913S1 Category Tags , ,
SPREAD THE LOVE

Description

REPLACE ForWhite Rodgers 120-105851120-105851-6 120-913S1M105171 AM103290AM30182AM52191 AM5394581777826277
Compatible With 100 108 110 111112 112L120 140 20010 212 214 216 300 Serial Numbers Below-095000 312 314 316erial Numbers Below-095000
SPECHeavy Duty Relay 12 Volt 3 Terminal Continuous Duty
NOTEMounting options recommend coil terminals up oreval.Use caution when installing. Do not over tightenhe nuts/terminal posts
1 YEAR WARRANTYPlease feel free to contact us for anyuestions, we will give quick response asap
SPEC
Voltage: 12V
Terminals: 3
DutyContinuous
High Current Stud: Around 5/16 Inch
Low Current StudAround 10-32 Inch
Mounting Type: Flat 180
Contacts Material: Red Copper
Housing Material: Nylon TA6
Potted coil: Copper
Resistance:5.6
Work Current: 200A
Inrush Current: 240A
REPLACE For
White Rodgers 120-105851 120-105851-6 120-913S1
AM105171 AM103290 AM30182 AM52191 AM53945
Compatible With
100 108 110 111 112 112L 120 140 200 210 212 214 216 300 Serial Numbers Below-095000 312 314 316 Serial Numbers Below-095000
