Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8×8 and 6×6 Mowe

Categories
Product tags
air filter axle bearing belt bracket brake brake cable brake disc carburetor car lamp car light centrifugal clutch clutch clutch cable clutch parts clutch pulley disk brake drive belt electromagnetic valve front fork gasket holder ignition coil ignition spark booster jump-spark coil Lamps Lift Kit Lights lowering kit protective cover pulley clutch shaft shock absorber solenoid solenoid valve spark coil sparking coil starter motor switch throttle cable tire tool tyre washer wheel hub
Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8x8 and 6x6 Mowe
Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8x8 and 6x6 Mowe - Image 2
Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8x8 and 6x6 Mowe - Image 3
Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8x8 and 6x6 Mowe - Image 4
Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8x8 and 6x6 Mowe - Image 5

Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8×8 and 6×6 Mowe

SKU DCF.01862 L19-11222 Category Tags , ,
SPREAD THE LOVE

Description

Carb fuel shut off control solenoid replaces Kawasaki 21188-2006 21188-2014, MIU11222, and KM-21188-2014
Fits Kawasaki FD620 FD620D FD661 FD661D Lawn Mower
Also fits Argo Conquest 8×8 and 6×6 mower
Outside threads: 7.83mm, Inside threads: 7.45, Overall length: 57.60mm Plunger diameter top: 1.75mm Plunger diameter bottom: 2.33mm Plunger length: 10.20mm
Please retest the solenoid valve and make sure it is connected correctly. When you connected 12 VDC and an adequate ground the solenoid functions as it should
Carburetor Fuel Shut Off Solenoid Replaces 21188-2006, 21188-2014, MIU11222, KM-21188-2014 for Kawasaki FD620 FD620D FD661 FD661D Lawn Mower and Argo Conquest 8×8 and 6×6 Mower
Features
Carb fuel shut off control solenoid replaces Kawasaki 21188-2006 21188-2014, MIU11222, and KM-21188-2014
Fits Kawasaki FD620 FD620D FD661 FD661D Lawn Mower
Also Argo Conquest 8×8 and 6×6 Mower
Outside threads: 7.83mm, Inside threads: 7.45, Overall length: 57.60mm Plunger diameter top: 1.75mm Plunger diameter bottom: 2.33mm Plunger length: 10.20mm
