PRODUCT PARAMETER- Voltage – 12V, power 250A, capacity – 2000-5000lbs, for ATV Winch Solenoid Relay Contactor Switch 12V 250 AMP 1500lb-5000lb Application.
HIGH QUALITY – Made of strong, weather-resistant steel and powder-coated black surface, with super durability. OEM of high quality KFI winch kit is a great alternative to replace contactor.
MULTIFUNCTIONAL APPLICATION- For ATV Winch Solenoid Relay Contactor Switch 12V 250 AMP 1500lb-5000lb Application. Direct Replacement for UTV ATV Winch Solenoid Relay Contactor Switch 12V 250 AMP.
INSTALLATION GUIDE- Easy to install. The two wires – Green and Black which go to the switch that controls In and Out on a winch. Blue and yellow go to motor, Black and red go to battery.
AFTER-SALES SERVICE- If the product fails or other problems, you can contact us at any time, we will solve the problem for you within 12 hours.
Power: 250 A
Working Voltage: DC 12V
Life Time: >10,000 times
OEM reference – 63070, 62135, 74900, 2875714, 70715
Relay Size – approx 4.33″ x 1.57″ x 2.76″ (110mm x 60mm x70mm),Winch Solenoid easy to control and easy to operate, it reverses the polarity of the winch motor to A to control the position of the switch.
Easy Installation
Blue To Winch positive
Yellow To winch negative
Red To battery positive
Black To battery negative,Package Include:
1 x DC 12V Relay Winch Solenoid
6 x Insulated protecting Waterproof caps
