Technical details & ApplicationsVoltage: 12V; Capacity:2000-5000lbs; The Stud is 1/4 ;/ For ATV Winch Solenoid Relay Contactor Switch 12V 250 AMP 1500lb-5000lb Application
Premium qualityGreat Alternative to OEM,Heavy duty and Replacement Contactor for KFI Winch Kits; It Functions As Reversing the Polarity On the Winch-motor As a function of the control-switch position.
Application – For ATV Winch Solenoid Relay Contactor Switch 12V 250 AMP 1500lb-5000lb Application
LIFETIME WARRANTY100% high quality & oem Match, direct replacement; Free Return and Full Refund
Note: The Switch is a momentary center-off SPDT type. It is designed to handle intermittent current loads of 250 amps for up to 10 seconds, requiring a 20-30 second cooling time between cycles
WINCH RELAY Kit

WINCH RELAY

WINCH SOLENOID

Package Include
1 X New Solenoid Relay
1 X Handbar Switch
1 X balck case
1 X flat mount
2 X Curved mount
Nuts & Screws
1 X Installation manual
6 X Insulated protecting Waterproof caps
Specification
Voltage: 12 VDC Rating: 250A
Life Time: >10,000 times
Seal Level: IP67
OEM reference 63070, 62135, 74900, 2875714, 70715
DIMENSIONS: 4.41 (L)* 1.69 (W)* 2.81 (H) inch/ 112*43*71.3 mm
Easy Installation
Blue To Winch positive
Yellow To winch negative
Red To battery positive
Black To battery negative
Winch Motor Solenoid

12V WINCH SWITCH

WINCH SOLENOD RELAY

Winch Motors Balanced Bridge
it Reverse as the Balanced Bridge On the Winch-motor and as a function of the control-switch position.
The Winch Relay is a momentary center-off SPDT type, handle intermittent current loads of 250 amps for up to 10 seconds, requiring a 20-30 second cooling time between cycles
Water And Weather Resistant
Thermoplastic Shell and Powder Coated Black Surface for great durability
Give you the green light to go extreme through any water conditions.
Heavy Duty
All Mounts are Metal-Plating before they are coated & 180 Copper Wire as Coil Reduce the Power Loss, Longer the Using LifeAvoid corrosion
Life Expectancy Electrical: 10,000 times Operations
