Replaces OEM Part Numbers: Exmark 1-601979, 1-603463, 1-603539, 1-611190, 1-611223, 601979, 603463, 603539, 611190, 611223, Ferris 1521823, 21823, 5021823, Scag 461074, 481633, 48786
Compatible with Models: Turf Tracer Hydro 1992-2001 (FMD-52)(FMD-60)(TTH-14K)(TTH18KO)(TTH-16BV)(TTH-18KC)(TTH-20KC)(TTH-22KC)(FMD523)(FMD603)(TT18KC)(TT19KA)(TT22KC)(TT23KA)(TT23KC), Turf Tracer Five
Compatible with Models: Scag SSZ-16BV, SSZ-18BV, SSZ-18CV, SSZ-18CV, SSZ-18CV-48, SSZ-18KH, SSZ-20CV, SSZ-22CV, SSZ4216BV, SSZ4816BV, SSZ4818CV, STHM-20CV, STHM-22CH, STHM-22CV-40000,
Compatible with Models: Scag SW48-16BV, SWZ-14KA, SWZ-14KH, SWZ-16BV, SWZ-16BV-40000, SWZ-16BV-50001, SWZ-16BVE, SWZ-16BVE-50001, SWZ-18BV, SWZ-18BV-40000, SWZ-18BV-50001, SWZ-20CVE, SWZ-20CVE-40000,
Shaft Diameter: 1 Inch; Pulley Outer Diameter: 6.10 Inch; High-Performance Gen 3 PTO Clutch; 370 Degrees Auto Thermal Cutoff Preventing Clutch Damage
PTO Clutch Part Number 810-CPT2330O
Gen 3 Power Take Off Clutch
Includes: Gen 3 Electric PTO Clutch
Compatible with the following brands: Exmark,Ferris,Scag,Simplicity,Snapper,Snapper Pro,Warner
Compatible with the following models: Turf Tracer Hydro SWZ Series
Replaces for the following OEM MPN’s: 1-601979, 1-603463, 1-603539, 1-611190, 1-611223, 601979, 603463, 603539, 611190, 611223, 1521823, 21823, 5021823, 461074, 481633, 48786, 21823SM, 5021823SM, 29678, 7029678, 7029678YP, 5215-13, 5215-99, 255-383
Torque (Newton Metre): 150Nm (110ft-lb)
Resistance at 70F (Ohms): 2.520.1
Current (Amps): 4.76
Available Bores: 1″,1-1/8″
Clutch Rotation: CW,CCW
Connection: Lead Wire
GEN 3 PTO Clutch
1-601979, 1-603463, 1-603539, 1-611190, 1-611223, 601979, 603463, 603539, 611190,

611223, 1521823, 21823, 5021823, 461074, 481633, 48786, 21823SM, 5021823SM,

29678, 7029678, 7029678YP, 5215-13, 5215-99, 255-383

Life: B10 life of 25,000 cycles at 2000 hours
Environment: Ambient -40F to +200F
Performance Enhancement: Friction Ring
Bearing Operating Temperatures (-40F to +350F)
Coil Operating Temperatures (-40F to +350F)
Temperature Fuse Melting Point of Coil 365F
Operating Speed: Input speeds up to 3600 rpm
Stop Time: 4 seconds
Voltage Insulation: 1000V

The GEN 3 Difference
Stainless steel leaf springs
Better dynamic balance with reduced pulley weight
370F auto thermal cutoff preventing clutch damage
Increased blade acceleration with higher initial torque
Enhanced stopping time with superior spring brake system
Anti high & low temperature bearing and encapsulated coils (-40F to 370F) for consistent performance
