Fits: 44″, 46″ 50″, venttilated decks using star shaped center hole blades.
Replaces AYP: 143651, : 532 14 36-51
This complete Spindle / Mandrel Assy Replaces parts 137152 137553 110485X 137266
Height: 4 7/8″ ; Cast Aluminum Housing
CONTENTS: Used with star center hole blades, comes with 3 bolts with threads.
3spindle assemblies (also called Mandrel) for AYP, replaces part number 143651. Used on , Poulan, , Wizard More. Also replaces part number 532143651.
Includes housing (137152), Shaft With Bearings (137553) and Hardware.
Includes Hardware for mounting bolts (3 138776, 15772), Blade Bolt With Washers (850857), Spacer (129963) and Pulley Locknut (137266, 139729). Pulley is not included.
The three mounting holes are pre-tapped for easier installation. Most replacement (and the FSP) 143651 spindles are not tapped and are more difficult to install. The top of the shaft is splined for spline type pulleys and the bottom of the shaft has the AYP 5 point star pattern.
Very important when installing the pulley to put the spacer under the pulley (between the pulley and top bearing). If installed without a spacer or with the spacer on top of the pulley damage will occur to the shaft and pulley.
AYP (maker of , Poulan, , YardPro, WeedEater, Wizard more) .used this spindle on 3 blade decks 44″ (rare, 1993-1994 only), 46, and 50″ decks, 1993 to 2001.
Please check owners parts list for proper application or send us your model number and we will check for you.
