2 Linear Actuator 150mm 6″ Stroke 330 Pound Max Lift Heavy Duty DC 12Volt Motor
Linear actuators are widely used in many industries, such as electric power, machinery, metallurgy, mine, petroleum, chemical industry, transportation, lifting, construction, food and feed processing and so on. With reliable performance, sensitive action stable running, the same characteristics of push and pull and good environment adapt- ability etc.
We also provide the
Positive Inversion Controller
for the linear actuator, if you need, Pls
Click Here

2 Linear Actuator 150mm 6″ 330 Pound Max Lift Heavy Duty DC 12Volt Motor
Note: We have paired the 2PCS linear actuators and can guarantee 95%
synchronization for them.
Product Name
Linear Actuator
Condition
100% New
Input Voltage
DC 12V
Stroke Length
150mm/6″
Retracted Length
260mm/10.24″
Extended Length
410mm/16.14″
Max Push Load
1500N/150KG/330lbs
Max Pull Load
1200N/120kg/264lbs
Speed
5.7mm/s (0.22″/s)
Power Cord Length
1.5Meters/59″
Duty Cycle
25%
Operating Frequency
20%
Material
Aluminum Alloy
Color
Silver Grey
Operation Temperature
-26 C ~ +65 C
Protection Class
IP65
No-load Current
< 0.5A
Max load Current
3A
Certification
CE SGS
Warranty
Standard 1 year
Maintenance
Free-maintenance
Stroke Length
50mm
100mm
150mm
200mm
250mm
300mm
350mm
400mm
450mm
Retracted Length
