740mm Go Kart Rear Axle Kit + Front Steering Wheel Assembly +48V 1800W Motor Set
Full Set of reliable powerful 48v 1800w brushless electric motor controller and other necessary components.

Max power: 1800w-2000w, Rated torque: 3.5-10N.m, Rotating speed: 4300-4500RPM

Brushless motor is much better than brushed motor, it’s high efficiency, powerfrugal, low noise, Long lifespan, stable…

Applicable to go karts, scooters, e-bike, atv, motorized bicycle,
moped, mini bikes, pocket bikes, electric dirt bikes, etc.

EASY TO INSTALL-we have instructions to make
your installation easier, For the guide video can search for “https://www.youtube.com/watch v=APRoSdOSf0c” on
YouTube. Each motor kit is tested many times before it is packaged and
leave the factory.Any other problem,please contact us by ebay message.
Package Contents
1 x Motor
4 x Battery
1 x Charger
1 x Controller
1 x LCD Throttle w/ ignition switch
1 x Throttle Pedal
1 x Terminal Block
1 x Wiring Harness
1 x Forward / Reverse Switch
1 x Brake switch
1 x Charger port
2 x Battery Wires
1 x T8F Chain only
1x T8F Sprocket (29mm)
1x 3 speed switch
1x 740mm Axle Kit w/ Pillow block bearing, disc rotor, brake caliper cylinder, rear wheel hubs (the thickest part of the axle is 22mm, the length is 740mm, the wheel hub fits 6 inch wheels (rim) with 3 bolt pattern and 78mm bolt to bolt space
)
4x 4.10-6 wheels
2x stub axle
2x front wheel hubs
1x steering Wheel
1x Front steering Tie Rod Gear Rack

Motor Spec.
Model: 48VDC 1800W Brushless Motor
Sproket: T8F 9Teeth
Rated current: 28A
Max Current 40A
No-load current: 3.0A
Rated torque: 3.5-10N.m
Max power: 1800w-2000w
Motor weight: 10.5 lbs (4.8kg)
Rated rotating speed: 4300-4500RPM

Controller Spec.
Rated voltage: DC 48v
Current limit: 32A
Rated power: 1800w
Matching motor: DC Brushless motor
Under Voltage Protection: 42V

Why choose Brushless motor What is the advantages of brushless motor
1. Less electrical and electromagnetic noise
2. Long lifespan: No brushes to wear out, around triple lifespan as brushed motor
3. Low maintenance: No brushes to replace
4. Powerfrugal: Power consumption is 1/3 of brushed motor
5. High efficiency: Brushless motors are typically 85-90% efficient whereas brushed DC motors are around 75-80% efficient.
