Left And Right CV Axles Compatible with Suzuki Eiger Auto 4×4 LT-A400FC 2005 2006 2007 / Eiger 4×4 LT-F400F 2005 2006 2007
SPREAD THE LOVE
Description
Order Includes: 1x Front Left CV Axle, 1x Front Right CV Axle
Compatible with Suzuki models: Eiger Auto 4×4 LT-A400FC 2005-2007, Eiger 4×4 LT-F400F 2005-2007
Front Left CV Axle Part Number: 54902-38F23, 54902-38F10, 54902-38F20, 54902-38F22, 54902-38F01,54902-38F00
Front Right CV Axle Part Number: 54901-38F23, 54901-38F10, 54901-38F20, 54901-38F22, 54901-38F01, 54901-38F00
We strongly suggest comparing the posted picture to the unit(s) that needs to be replaced.
Compatible with Suzuki models:
Eiger 4×4 LT-F400F 2002-2004
Eiger Auto 4×4 LT-A400FC 2002-2004
Eiger 4×4 LT-F400F 2005-2007
Eiger Auto 4×4 LT-A400FC 2005-2007
Part Number and Specifications:
Front Left CV Axle : 54902-38F23, 54902-38F10, 54902-38F20, 54902-38F22, 54902-38F01,54902-38F00
Length: 514.35 mm | 20.25 ”
Spline A Length: 51 mm | 2.0 ”
Spline A Boot Width: 73.2 mm | 2.88 ”
Spline A – 20 Tooth
Spline B Length: 28.51 mm | 1.12 ”
Spline B Boot Width: 71 mm | 2.79
Spline B – 20 Tooth
Front Right CV Axle: 54901-38F23, 54901-38F10, 54901-38F20, 54901-38F22, 54901-38F01, 54901-38F00
Length: 563.9 mm
Spline A Length: 51 mm | 2.01 ”
Spline A Boot Width: 73.1 mm | 2.87 ”
Spline A – 20 Tooth
Spline B Length: 28.5 mm | 1.12 ”
Spline B Boot Width: 70.2 mm | 2.76 ”
Spline B – 20 Tooth
