Contacts:Normally Open (NO)/ Flat Base Metal Case / 10-32 Terminal
3 Pole Battery Isolation Solenoid, 12VDC With 2 Copper Point,Housing plated Steel Case / 180Flat mounting bracket./ Mounting holes: 5/16 x 19/32, 2-13/64 on centers.
Our Coil Roll is using 180 Copper. Max Current Above 200amp/ Rate Current: 100A / Our Cover is Environmental Plating,Sealed Unit Protects Solenoid From The Elements Helping Prevent Corrosion
INSTIALLOne side goes to Battery, opposite side to starter, top screw which is smaller goes to switch or key start only. It is already grounded internal.
Note:If it is the energizing circuit which is typically 16/18 Awg , suggest a 5amp fuse;If 10 Awg wire suggest 30 amp auto cicuit breaker; If high output alternator, suggest an 8 Awg wire with a 50 Amp auto circuit breaker
Heavy Duty
180 copper coil wire rolls upgrade the conductivity of the product
Max Transient Current can reach 200Amp
Water-Resistant
Zinc-Plating Outer and Potted Coil Interiors protect YOUR solenoid against any harsh environment
Dustproof
Firmly Enclosed for overall protection from dust, dirt, sand and any other substance that could cause damage to YOUR Solenoid.
Replacement
100% OEM Match and Replacement
