Voltage: DC 24 V, Stroke & Force: 1.38 in, 1.6 N, Current: 0.5 A, Power: 12 W
Duty Cycle: Continuous Duty, Body Frame Size: 1.18 x 1.5 x 3.27 in (38 x 30 x 84 mm) Total Length: 7.03 in (179 mm)
Weight: 16.9 oz (480 g), Lead Wire Length : 7.09 in, Wire Type: UL1007, AWG20
Plunger Diameter: 12 dia., Plunger Bar Diameter: 0.118 in (3mm), Screw pitch 0.02 in (0.5mm)
Operating Temperature : -5 – 40 Celsius non-freezing, non-condensing, Package Included: 1x DC solenoid
Size:Stroke 1.38 (in)
|
Style:DC 24v Force 160g Duty cycle 100%
Long stroke solenoid have 35 mm stroke. You can use it as both of push and pull solenoids. Long stroke solenoids work at any points that coventional solenoids dont work such as Industrial equipments etc.
