Rear Axle Drive Shaft Kit For Kawasaki Mule 4010 KAF950 Diesel 4X4 2009-23 L/ R
SPREAD THE LOVE
Description
Premium Quality Replacement Part
We strongly suggest comparing the posted picture to your faulty unit!
COMPLETE REAR LEFT and RIGHT
AXLE DRIVE SHAFT with BEARINGS and GASKET KIT
For KAWASAKI Models:
Mule 4010 KAF620-M 4×4 2009-2023
Mule 4010 Hardwoods Green HD KAF620-N 4×4 2009
Mule 4010 Trans Diesel Realtree APG HD KAF950-H 4×4 2010
Mule 4010 Trans Realtree APG HD KAF620-S 4×4 2010-2012
Mule 4010 Trans KAF620-S Camo 4×4 2014-2021
Mule 4010 Diesel KAF950-F 4×4 2009-2013
Mule 4010 Trans Diesel KAF950-G 4×4 2009-2013
Mule 4010 Trans KAF620-R 4×4 2009-2021
Mule 4010 KAF620-T 4×4 SE 2016-2018
Mule 4010 KAF620-V 4×4 SE 2016-2018
Mule 4010 Trans KAF620-X 4×4 2018
Mule 4010 KAF620Z 4×4 2022-2023
Mule 4010 Trans KAF620B 4×4 2022-2023
Mule 4010 Trans KAF620C 4×4 2022-2023
Mule 4010 Trans KAF620D 4×4 2022-2023
Part Numbers:
Axle Drive Shaft
39158-1120
39158-1119
Boot Drive Shaft
49006-1257
Ball Bearing
92045-1208 (6006) 30x55x13
Wheel Bearing
92045-0102 ( DAC2552W) 25x52x42
Gasket Drive Shaft Cover
11060-1251
Cliper Type-C
480J2800
Dimensions:
Length:18 2/8″ | 463.50 mm (24 Tooth)
Length: 9 1/8″ | 231.75 mm (15 Tooth)
Tooth Inner Diameter: 0.98″ | 25 mm
Ball Bearing: 30 x 55 x 13
Wheel Bearing: 25 x 52 x 42
Order Includes:
4x Propeller Drive Shaft
4x Bearing
4x Boot
2x Circlip
2x Gasket
