Rear Brake Hub w/ Seal and Shoes NEW for Kawasaki ATV SxS 41038-0035 41038-1336

Rear Brake Hub w/ Seal and Shoes NEW for Kawasaki ATV SxS 41038-0035 41038-1336
Brand New Rear Brake Hub with Seal and Brake Pads
Fits Left or Right Side
Order Includes
1x Rear Wheel Hub Left/Right
1x Set Brake Shoes/Pads w/ Springs
1x Brake Hub Seal
Fits the Following KAWASAKI Models
Mule 3000 KAF620-G 2001-2008
Mule 3010 KAF620-E 4×4 2002-2008
Mule 3010 Diesel 4×4 KAF950B 2003-2008
Mule 3010 Trans 4×4 KAF620J 2005-2006
Mule 3010 Trans 4×4 KAF620-K 2005-2006
Mule 4000 KAF620 2009-2020
Mule 4010 4×4 KAF620M 2009-2021
Mule 4010 Diesel 4×4 KAF950F 2009-2013
Mule 4010 Trans 4×4 2021
Replaces KAWASAKI Part Numbers
Rear Wheel Hub | 41038-0035 | 41038-1336
Rear Brake Pads | 41048-1079 | 41048-1078 | 41048-7503 | 41048-7502
Rear Wheel Bolt | 92150-1366
Brake Hub Seal | 92093b 92093-1543
Dimensions & Measurements
BOLT SPACING | 95mm
BOLT DIAMETER | 14mm
SPLINE | Diameter 25mm 24t
BOLT / STUD | 1/2″-20
BOLT / STUD LENGTH | 1.4″ | 36.2mm
Brake Shoe Width | 26mm
Brake Shoe Pad Arc Distance | 151mm
Brake Shoe Thickness | 6mm
**
