Rear Differential Diff Rear Chunk 705502808 UPGRADE 2019+ ATV Outlander Renegade

Rear Differential Diff Rear Chunk 705502808 UPGRADE 2019+ ATV Outlander Renegade

SKU LJQ.04482 705502808 Category Tag
SPREAD THE LOVE

Description

This is the 2019+ rear differential found in Renegades 570 and larger and Outlanders 650 and larger.
This has the 6 inch (155mm) ring gear with straight cut teeth as shown.
It will fit g2 bikes (500/570/650/800/850/1000) if you are upgrading you will need to shorten your shaft 1.75″ or buy a kit from us, please see our other listings. (G1 bikes will require further modifications to work).
This has a provision for an abs sensor, but will fit bikes without a rear diff sensor
BRP claims 25% increase in load capacity on this gear set vs the spiral cut xmr final drive units (rear differentials) from 13-18 models.
Pinion spline count 20
Current part number 705502808
