Top End Gasket Set for Honda Rancher 420 TRX420FM2 4WD Manual 2014-2022
TRX420 Gasket set for Top End Rebuild
Kit Includes
1x Head Gasket
1x Base Gasket
1x Valve Cover Gasket
1x Crush Exhaust Gasket
-Head Gasket is composed of two layers of compressible metal core gasket material-
-Valve Cover Gasket is a single layer metal core gasket with Temp & Oil Resistant coating-
-Base Gasket is a single layer (.3mm) with UP label for proper install-
-Exhaust Gasket is a copper crush gasket-
Fits the Following Honda Fourtrax Models
Rancher 420 TRX420FA 4WD Auto 2009-2014
Rancher 420 TRX420FA2 4WD Auto 2014-2022
Rancher 420 TRX420FA5 4WD Auto 2015-2022
Rancher 420 TRX420FA6 4WD Auto 2015-2022
Rancher 420 TRX420FE 4WD Electric Shift 2009-2013
Rancher 420 TRX420FE1 4WD Electric Shift 2014-2022
Rancher 420 TRX420FM 4WD Manual 2009-2013
Rancher 420 TRX420FM1 4WD Manual 2014-2022
Rancher 420 TRX420FM2 4WD Manual 2014-2022
Rancher 420 TRX420FPA 4WD Power Steering Auto 2009-2014
Rancher 420 TRX420FPE 4WD Power Steering E Shift 2009-2013
Rancher 420 TRX420FPM 4WD Power Steering Manual 2009-2013
Rancher 420 TRX420TE 2WD Electric Shift 2009-2013
Rancher 420 TRX420TE1 2WD Electric Shift 2014-2022
Rancher 420 TRX420TM 2WD Manual 2009-2013
Rancher 420 TRX420TM1 2WD Manual 2014-2022
Rancher 420 TRX420FA1 4WD Auto 2014-2016
Replaces Honda Part Numbers
Head Gasket | 12251-HP7-A01
Base Gasket | 12191-HP5-601
Valve Cover/Head Cover Gasket | 12315-HP5-601
Exhaust Gasket | 18291-MN4-920
Dimensions & Measurements
Exhaust Crush Gasket
| ID 35.5mm | OD 43mm | Thickness 4.3mm |
**
